Optimized bow-tie metasurface and its application in trace detection of lead ion

Zhang Junqing; Wu Yiping; Chen Shenghao; Gu Shiyi; Sun Li; Zhou Ming; Chen Lin

doi:10.12086/oee.2021.210123

Article navigation > Opto-Electronic Engineering > 2021 Vol. 48 > No. 8 > 210123

Next Article Previous Article

Zhang J Q, Wu Y P, Chen S H, et al. Optimized bow-tie metasurface and its application in trace detection of lead ion[J]. Opto-Electron Eng, 2021, 48(8): 210123. doi: 10.12086/oee.2021.210123

Citation:

Zhang J Q, Wu Y P, Chen S H, et al. Optimized bow-tie metasurface and its application in trace detection of lead ion[J]. Opto-Electron Eng, 2021, 48(8): 210123. doi: 10.12086/oee.2021.210123

Optimized bow-tie metasurface and its application in trace detection of lead ion

1.
College of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
2.
Shanghai Key Laboratory of Modern Optical System, Shanghai 200093, China
3.
The Sino-British Collede, Shanghai 200031, China
4.
Shanghai Academy of Environmental Sciences, Shanghai 200233, China
5.
Institute of Intelligent Science and Technology, Tongji University, Shanghai 200092, China

Fund Project: National Natural Science Foundation of China (61671302), the Shuguang Program of Shanghai, China (18SG44), and Shanghai Academy of Environmental Sciences Innovation Foundation, China (2020190189)

More Information

^*Corresponding author: Chen Lin, E-mail: linchen@usst.edu.cn

Received Date 16 April 2021

Revised Date 09 August 2021

Published Date 15 August 2021

Abstract

Abstract

The strong localized plasmon resonance of metasurfaces makes the resonance frequency extremely sensitive to the dielectric environment, which can be applied to label-free environment detection. In this paper, a bow-tie terahertz metasurface with an optimized ratio of the quality factor to effective mode volume(Q/V_eff) is designed. The unit cell of the proposed structure is composed of a mirror-symmetrical metallic bow tie in the middle and continuous metallic strips on both sides. The width of each metal strip and the length of the bow-tie gap are optimized for the parameter Q/V_eff. When the metal strip width is 25 μm and the gap length is 2 μm, the effective mode volume is 3.6 μm³ and Q/V_eff is 2.2 μm^-3 at 0.7 THz. In the experiment, different concentration of the lead ion solution was dropped on the proposed metasurface. The transmission spectrum was measured by a terahertz time-domain spectroscopy system. The results showed that there is a linear relationship between resonance frequency shift and lead ion solution concentration from 0.1 ng/mL to 20 ng/mL. The detection limit is 0.1 ng/mL. The terahertz metasurface sensor has the advantages of the miniaturized size, easy sample preparation, fast measurement capability and real-time detection, which will be widely used in environmental protection and food safety.
- terahertz /
- metasurface /
- lead ion /
- effective mode volume /
- high sensitivity

FullText(HTML)

References

[1]	Aragay G, Pons J, Merkoçi A. Recent trends in macro-, micro-, and nanomaterial-based tools and strategies for heavy-metal detection[J]. Chem Rev, 2011, 111(5): 3433-3458. doi: 10.1021/cr100383r CrossRef Google Scholar
[2]	Dehouck P, Cordeiro F, Snell J, et al. State of the art in the determination of trace elements in seawater: a worldwide proficiency test[J]. Anal Bioanal Chem, 2016, 408(12): 3223-3232. doi: 10.1007/s00216-016-9390-6 CrossRef Google Scholar
[3]	Fu F L, Wang Q. Removal of heavy metal ions from wastewaters: A review[J]. J Environ Manage, 2011, 92(3): 407-418. doi: 10.1016/j.jenvman.2010.11.011 CrossRef Google Scholar
[4]	Wani A L, Ara A, Usmani J A. Lead toxicity: a review[J]. Interdiscip Toxicol, 2015, 8(2): 55-64. doi: 10.1515/intox-2015-0009 CrossRef Google Scholar
[5]	Arora M, Kiran B, Rani S, et al. Heavy metal accumulation in vegetables irrigated with water from different sources[J]. Food Chem, 2008, 111(4): 811-815. doi: 10.1016/j.foodchem.2008.04.049 CrossRef Google Scholar
[6]	Berlina A N, Zherdev A V, Dzantiev B B. Progress in rapid optical assays for heavy metal ions based on the use of nanoparticles and receptor molecules[J]. Microchim Acta, 2019, 186(3): 172. doi: 10.1007/s00604-018-3168-9 CrossRef Google Scholar
[7]	Singh H, Bamrah A, Bhardwaj S K, et al. Nanomaterial-based fluorescent sensors for the detection of lead ions[J]. J Hazard Mater, 2021, 407: 124379. doi: 10.1016/j.jhazmat.2020.124379 CrossRef Google Scholar
[8]	de Souza I D, de Andrade A S, Dalmolin R J S. Lead-interacting proteins and their implication in lead poisoning[J]. Crit Rev Toxicol, 2018, 48(5): 375-386. doi: 10.1080/10408444.2018.1429387 CrossRef Google Scholar
[9]	Wallace D R, Djordjevic A B. Heavy metal and pesticide exposure: A mixture of potential toxicity and carcinogenicity[J]. Curr Opin Toxicol, 2020, 19: 72-79. doi: 10.1016/j.cotox.2020.01.001 CrossRef Google Scholar
[10]	Acar O. Determination of cadmium, copper and lead in soils, sediments and sea water samples by ETAAS using a Sc + Pd + NHNO chemical modifier[J]. Talanta, 2005, 65(3): 672-677. doi: 10.1016/j.talanta.2004.07.035 CrossRef Google Scholar
[11]	Koçak S, Tokuşoğlu Ö, Aycan Ş. Some heavy metal and trace essential element detection in canned vegetable foodstuffs by differential pulse polarography (DPP)[J]. Electronic J Environ Agric Food Chem, 2005, 4: 871-878. Google Scholar
[12]	Goossens J, Moens L, Dams R. Inductively coupled plasma mass spectrometric determination of heavy metals in soil and sludge candidate reference materials[J]. Anal Chim Acta, 1995, 304(3): 307-315. doi: 10.1016/0003-2670(94)00643-Z CrossRef Google Scholar
[13]	Kot B, Baranowski R, Rybak A. Analysis of mine waters using X-ray fluorescence spectrometry[J]. Pol J Environ Stud, 2000, 9(5): 429-432. Google Scholar
[14]	Malitesta C, Guascito M R. Heavy metal determination by biosensors based on enzyme immobilised by electropolymerisation[J]. Biosens Bioelectron, 2005, 20(8): 1643-1647. doi: 10.1016/j.bios.2004.08.003 CrossRef Google Scholar
[15]	De A, Kumari A, Jain P, et al. Plasmonic sensing of Hg(Ⅱ), Cr(Ⅲ), and Pb(Ⅱ) ions from aqueous solution by biogenic silver and gold nanoparticles[J]. Inorg Nano-Met Chem, 2021, 51(9): 1214-1225. Google Scholar
[16]	Sadrolhosseini A R, Shafie S, Rashid S A, et al. Surface plasmon resonance measurement of arsenic in low concentration using polypyrrole-graphene quantum dots layer[J]. Measurement, 2021, 173: 108546. doi: 10.1016/j.measurement.2020.108546 CrossRef Google Scholar
[17]	Fen Y W, Yunus W M M, Yusof N A. Surface plasmon resonance optical sensor for detection of Pb²⁺ based on immobilized p-tert-butylcalix[4]arene-tetrakis in chitosan thin film as an active layer[J]. Sensor Actuat B: Chem, 2012, 171-172: 287-293. doi: 10.1016/j.snb.2012.03.070 CrossRef Google Scholar
[18]	Chen L, Liao D G, Guo X G, et al. Terahertz time-domain spectroscopy and micro-cavity components for probing samples: a review[J]. Front Inform Technol Electron Eng, 2019, 20(5): 591-607. doi: 10.1631/FITEE.1800633 CrossRef Google Scholar
[19]	Li B, Wang M H, Wang N, et al. Preliminary study on heavy metal detection in soil using terahertz time-domain spectroscopy[C]//2011 Louisville, Kentucky, August 7-10, 2011: 1100020(doi: 10.13031/2013.37181). Google Scholar
[20]	Li B, Wang M H, Cao W, et al. Research on heavy metal ions detection in soil with terahertz time-domain spectroscopy[J]. Proc SPIE, 2011, 8195: 81951V. doi: 10.1117/12.902302 CrossRef Google Scholar
[21]	Lin S J, Xu X L, Hu F R, et al. Using antibody modified terahertz metamaterial biosensor to detect concentration of carcinoembryonic antigen[J]. IEEE J Sel Top Quantum Electron, 2020, 27(4): 6900207. Google Scholar
[22]	Yang Y P, Xu D Q, Zhang W L. High-sensitivity and label-free identification of a transgenic genome using a terahertz meta-biosensor[J]. Opt Express, 2018, 26(24): 31589-31598. doi: 10.1364/OE.26.031589 CrossRef Google Scholar
[23]	Qin B Y, Li Z, Hu F R, et al. Highly sensitive detection of carbendazim by using terahertz time-domain spectroscopy combined with metamaterial[J]. IEEE Trans Terahertz Sci Technol, 2018, 8(2): 149-154. doi: 10.1109/TTHZ.2017.2787458 CrossRef Google Scholar
[24]	Singh R, Cao W, Al-Naib I, et al. Ultrasensitive terahertz sensing with high-Q Fano resonances in metasurfaces[J]. Appl Phys Lett, 2014, 105(17): 171101. doi: 10.1063/1.4895595 CrossRef Google Scholar
[25]	Zengin G, Wersäll M, Nilsson S, et al. Realizing strong light-matter interactions between single-nanoparticle plasmons and molecular excitons at ambient conditions[J]. Phys Rev Lett, 2015, 114(15): 157401. doi: 10.1103/PhysRevLett.114.157401 CrossRef Google Scholar
[26]	Chen X X, Chen Y H, Qin J, et al. Mode modification of plasmonic gap resonances induced by strong coupling with molecular excitons[J]. Nano Lett, 2017, 17(5): 3246-3251. doi: 10.1021/acs.nanolett.7b00858 CrossRef Google Scholar
[27]	Srinivasan K, Borselli M, Painter O, et al. Cavity Q, mode volume, and lasing threshold in small diameter AlGaAs microdisks with embedded quantum dots[J]. Opt Express, 2006, 14(3): 1094-1105. doi: 10.1364/OE.14.001094 CrossRef Google Scholar
[28]	Gupta M, Singh R. Terahertz sensing with optimized Q/V_eff metasurface cavities[J]. Adv Opt Mater, 2020, 8(16): 1902025. Google Scholar
[29]	Chen Y Q, Bi K X, Wang Q J, et al. Rapid focused ion beam milling based fabrication of plasmonic nanoparticles and assemblies via "Sketch and Peel" strategy[J]. ACS Nano, 2016, 10(12): 11228-11236. Google Scholar
[30]	Chen Y Q, Xiang Q, Li Z Q, et al. "Sketch and Peel" lithography for high-resolution multiscale patterning[J]. Nano Lett, 2016, 16(5): 3253-3259. Google Scholar
[31]	Hu J Y, Li Z, Zhai C Y, et al. Plasmonic photo-assisted electrochemical sensor for detection of trace lead ions based on Au anchored on two-dimensional g-C₃N₄/graphene nanosheets[J]. Rare Met, 2021, 40(7): 1727-1737. doi: 10.1007/s12598-020-01659-z CrossRef Google Scholar

Overview

Overview

Overview: Lead ion pollution in water is becoming a serious worldwide environmental problem. Effective and efficient detection of lead ion pollution requires sensitive and selective sensors with rapid on-site detection ability for performing the desired detection. Traditional spectroscopy, electrochemical, and inductively coupled plasma mass spectrometry (ICP-MS) methods for lead ion detection have some problems, such as complex experimental technology, long measuring period, expensive equipment and so on, which are only suitable for laboratory analysis. In this direction, one appropriate alternative approach is exploring plasmonic metasensor technology for low-level lead ion detection, which offers sophisticated opportunities in lead ion detection and ecological environment protection. Terahertz wave has unique characteristics of low photon energy, excellent security and the nonionizing effect. Metasurfaces are promising tools that have facilitated precise screening and recognition of diverse molecules and biomolecules through substantial field confinement at subwavelength geometries. The terahertz metasurface sensor stems from its capability to squeeze electromagnetic fields, simultaneously in frequency and space. However, the radiative and nonradiative losses limit the quality factor (Q) of the metasurface. The observation and study of the effectively low mode volume (V_eff) were firstly reported in the middle of the twenty century, which was primarily established based on quantum electrodynamics. Metasurface designs with Q/V_eff cavities become extremely important for enhancing the light-matter interaction.

In this work, we demonstrate a modified bow-tie terahertz metasurface platform containing a micron-sized cavity with an optimized Q/V_eff value. The structural unit is composed of a mirror symmetrical metallic bow tie in the middle and two continuous metallic strips on both sides. Continuous metallic strip enhances the overall capacitance of metasurface unit cell, which allows the capacitive split gap cavity to store larger electromagnetic energy. When the continuous metal strip width is 25 μm and the gap size is 2 μm, the Q/V_eff of the proposed bow-tie terahertz metasurface reaches a maximum of 2.2 μm^-3 at 0.7 THz. For 4 µm thick analyte layer, and the sensitivity is about 80 GHz/RIU (refractive index unit), which is higher than traditional bow tie metasurface. The proposed metasurface is manufactured using a surface micromachining process and characterized by a THz time-domain spectroscopy (THz-TDS) system. For the lead ion solution with different concentrations, the experimental results indicate that the resonance frequency of the terahertz metasurface sensor decreases with the increase of the concentration of lead ion solution on the surface. When the concentration of lead ion solution ranges from 0.1 ng/mL to 20 ng/mL, the resonance frequency shift shows good linearity to the concentration of lead ion solution and the limit of detection (LOD) reaches 0.1 ng/mL. It is expected to provide a new lead ion solution detection scheme for the field of environmental protection and food safety.
