Optimizing the location of multiple laser guide stars in ground layer adaptive optical systems

Li Caifeng; Jia Peng; Cai Dongmei

doi:10.12086/oee.2020.190515

Article navigation > Opto-Electronic Engineering > 2020 Vol. 47 > No. 9 > 190515

Next Article Previous Article

Li C F, Jia P, Cai D M. Optimizing the location of multiple laser guide stars in ground layer adaptive optical systems[J]. Opto-Electron Eng, 2020, 47(9): 190515. doi: 10.12086/oee.2020.190515

Citation:

Li C F, Jia P, Cai D M. Optimizing the location of multiple laser guide stars in ground layer adaptive optical systems[J]. Opto-Electron Eng, 2020, 47(9): 190515. doi: 10.12086/oee.2020.190515

Optimizing the location of multiple laser guide stars in ground layer adaptive optical systems

1.
Institute of Physics and Optoelectronics, Taiyuan University of Technology, Taiyuan, Shanxi 030024, China
2.
Key Laboratory of Advanced Transducers and Intelligent Control Systems, Ministry of Education and Shanxi Province, Taiyuan, Shanxi 030024, China
3.
Center for Advanced Instrumentation, Durham University, Durham DH1 3LE, UK

Fund Project: Supported by National Natural Science Foundation of China (11503018, U1631133), Shanxi Province Science Foundation for Youths (201901D211081), Research and Development Program of Shanxi (201903D121161), the Scientific and Technological Innovation Programs of Higher Education Institutions in Shanxi (2019L0225)

More Information

^*Corresponding author: Jia Peng, E-mail: robinmartin20@gmail.com

Received Date 02 September 2019

Revised Date 02 December 2019

Published Date 15 September 2020

Abstract

Abstract

At present, the ground layer adaptive optical systems are using multiple laser guide stars arranged in regular polygons as reference targets to measure the effects of atmospheric turbulence. Obtaining the optimal position of laser guide stars becomes an interesting problem to analyze. This paper proposes a method to obtain the optimal position of laser guide stars by using a genetic algorithm as the optimization algorithm and a simplified geometry model of the ground layer adaptive optic system as the evaluation function. Furthermore, multi-process, Numba library, and multi-thread techniques methods are used to accelerate calculation speed. Based on these methods, real atmospheric turbulence profiles are used to analyze the relationship between the optimal position of laser guide stars with different numbers and the different atmospheric turbulence profiles from the same site, through an example of a ground layer adaptive optics system with 14 arcmin field of view. The results show that the optimal position of laser guide stars in the same site is almost the same and their statistically optimal positions are all regular polygon. Besides, we also find that the spatial resolution of turbulence profiles has strong effects to positions of laser guide stars, showing that the more equivalent layers in the measurement results, the closer the position distribution of laser guide stars is to the regular polygon.
- laser guiding stars /
- atmospheric turbulence /
- genetic algorithm /
- location optimization /
- algorithm to accelerate

FullText(HTML)

References

[1]	Osborn J, Wilson R, Butterley T, et al. Profiling the surface layer of optical turbulence with SLODAR[J]. Monthly Notices of the Royal Astronomical Society, 2010, 406(2): 1405–1408. Google Scholar
[2]	Rigaut F. Ground-conjugate wide field adaptive optics for the ELTs[C]//European Southern Observatory Conference & Workshop, 2002. Google Scholar
[3]	Hart M, Milton N M, Baranec C, et al. A ground-layer adaptive optics system with multiple laser guide stars[J]. Nature, 2010, 466(7307): 727–729. doi: 10.1038/nature09311 CrossRef Google Scholar
[4]	Rabien S, Angel R, Barl L, et al. ARGOS at the LBT. Binocular laser guided ground-layer adaptive optics[J]. Astronomy and Astrophysics, 2019, 621: 21. Google Scholar
[5]	李敏, 江长春, 魏凯, 等. TMT激光导引星系统设计[J].光电工程, 2018, 45(3): 170735. doi: 10.12086/oee.2018.170735 CrossRef Google Scholar Li M, Jiang C C, Wei K, et al. Design of the TMT laser guide star facility[J]. Opto-Electronic Engineering, 2018, 45(3): 170735. doi: 10.12086/oee.2018.170735 CrossRef Google Scholar
[6]	姜文汉.自适应光学发展综述[J].光电工程, 2018, 45(3): 170489. doi: 10.12086/oee.2018.170489 CrossRef Google Scholar Jiang W H. Overview of adaptive optics development[J]. Opto-Electronic Engineering, 2018, 45(3): 170489 doi: 10.12086/oee.2018.170489 CrossRef Google Scholar
[7]	饶长辉, 朱磊, 张兰强, 等.太阳自适应光学技术进展[J].光电工程, 2018, 45(3): 170733. doi: 10.12086/oee.2018.170733 CrossRef Google Scholar Rao C H, Zhu L, Zhang L Q, et al. Development of solar adaptive optics[J]. Opto-Electronic Engineering, 2018, 45(3): 170733. doi: 10.12086/oee.2018.170733 CrossRef Google Scholar
[8]	周昶宁, 阎吉祥, 俞信, 等.自适应光学系统中大气湍流的模型分析与计算机仿真[J].光学技术, 2005, 31(2): 249–251. Google Scholar Zhou C N, Yan J X, Yu X, et al. Model analysis and computer simulation of atmosphere turbulence in adaptive optics system[J]. Optical Technique, 2005, 31(2): 249–251. Google Scholar
[9]	Jia P, Osborn J, Kong L T, et al. Modelling synthetic atmospheric turbulence profiles with temporal variation using Gaussian mixture model[J]. Monthly Notices of the Royal Astronomical Society, 2018, 480(2): 2466–2474. doi: 10.1093/mnras/sty1951 CrossRef Google Scholar
[10]	蔡冬梅, 王昆, 贾鹏, 等.功率谱反演大气湍流随机相位屏采样方法的研究[J].物理学报, 2014, 63(10): 104217. Google Scholar Cai D M, Wang K, Jia P, et al. Sampling methods of power spectral density method simulating atmospheric turbulence phase screen[J]. Acta Physica Sinica, 2014, 63(10): 104217. Google Scholar
[11]	张智露.室内大气湍流模拟系统的研究[D].太原: 太原理工大学, 2017. Google Scholar Zhang Z L. Research on the simulation system of indoor atmospheric turbulence[D]. Taiyuan: Taiyuan University of Technology, 2017.http://cdmd.cnki.com.cn/Article/CDMD-10112-1017832272.htm Google Scholar
[12]	刘超.激光导星高精度波前探测与重构方法研究[D].长春: 中国科学院长春光学精密机械与物理研究所, 2018. Google Scholar Liu C. Study on laser guide star high precise wavefront sensing and reconstruction methods[D]. Changchun: Changchun Institute of Optics, Fine Mechanics and Physics Chinese Academy of Sciences, 2018.http://cdmd.cnki.com.cn/Article/CDMD-80139-1018189010.htm Google Scholar
[13]	Jia P, Basden A, Osborn J. Ground-layer adaptive-optics system modelling for the Chinese large optical/infrared telescope[J]. Monthly Notices of the Royal Astronomical Society, 2018, 479(1): 829–843. Google Scholar
[14]	王红帅, 姚永强, 刘立勇.大气光学湍流模型研究进展[J].天文学进展, 2012, 30(3): 362–377. Google Scholar Wang H S, Yao Y Q, Liu L Y. A review of atmospheric optical turbulence modeling research[J]. Progress in Astronomy, 2012, 30(3): 362–377. Google Scholar
[15]	Jia P, Cai D M, Wang D, et al. Simulation of atmospheric turbulence phase screen for large telescope and optical interferometer[J]. Monthly Notices of the Royal Astronomical Society, 2015, 447(4): 3467–3474. doi: 10.1093/mnras/stu2655 CrossRef Google Scholar
[16]	Osborn J, Wilson R W, Sarazin M, et al. Optical turbulence profiling with stereo-SCIDAR for VLT and ELT[J]. Monthly Notices of the Royal Astronomical Society, 2018, 478(1): 825–834. doi: 10.1093/mnras/sty1070 CrossRef Google Scholar
[17]	Els S G, Schoeck M, Seguel J, et al. The Multi Aperture Scintillation Sensor (MASS) used in the site selection of the Thirty Meter Telescope (TMT)[J]. Proceedings of SPIE, 2008, 7012: 701222. doi: 10.1117/12.788954 CrossRef Google Scholar
[18]	张琛, 詹志辉.遗传算法选择策略比较[J].计算机工程与设计, 2009, 30(23): 5471–5474, 5478. Google Scholar Zhang C, Zhan Z H. Comparisons of selection strategy in genetic algorithm[J]. Computer Engineering and Design, 2009, 30(23): 5471–5474, 5478. Google Scholar
[19]	Hussain E A, Alrajhi Y M. Accelerated genetic algorithm solutions of some parametric families of stochastic differential equations[J]. International Journal of Scientific & Technology Research, 2015, 4(1): 237–243. Google Scholar

Overview

Overview

Overview: The ground layer adaptive optic system (GLAO) uses wavefront sensors to measure wavefront errors from several different field of views and corrects the 'mean' wavefront errors from these measurements with a deformable mirror, which could slightly increase image quality in a wide field of view. The GLAO is particular useful for multi object observations, such as multi-object spectroscopic observations and wide field astrometry or photometry. The GLAO system normally assumes that there is a ground layer atmosphere turbulence in a fixed height, and thus it uses several laser-guide stars with fixed positions in the field of view to measure wavefront errors from that layer. However, the atmospheric turbulence is a stochastic medium and the height and strength of the ground layer will change continuously in real applications. Does there still exist optimal positions for these laser guide stars? Calculating the performance of the GLAO system with different configurations under different turbulence profiles is a straight forward method to obtain the optimal position of laser guide stars, but it will cost a very long time. In this paper, a simplified geometric model is proposed to evaluate the performance of the GLAO system. The genetic algorithm is used to obtain optimal positions of laser guide stars for different turbulence profiles from real measurements of different sites. Because there is a huge amount of atmospheric turbulence profiles, multi-processing, Numba library, and multi-thread techniques are used to further accelerate the computation speed up 3240 times that of the ordinary method. Based on the aforementioned methods, we have evaluated the GLAO performance with laser guide stars of different locations under different turbulence profiles from Paranal and Mauna Kea. We assume the turbulence profiles as random variables of independent and identically distributed and random sample a small batch (2000 turbulence profiles from different sites) to estimate the optimal position of laser guide stars. We have found that the optimal position of laser guide stars in the same site is almost the same and their statistically optimal positions are all regular polygon. However, we have also found that the spatial resolution of atmospheric turbulence profile measurements has strong impacts to the performance evaluation, showing that higher spatial resolution can lead to a more concentrated distribution of the laser guide stars. It indicates that it is necessary to obtain enough high-resolution turbulence profile data to better evaluate site conditions for China future large telescopes with GLAO systems.
