3D laser point cloud clustering method based on image information constraints

Xia Jinze; Sun Haoming; Hu Shenghui; Liang Dongtai

doi:10.12086/oee.2023.220148

Article navigation > Opto-Electronic Engineering > 2023 Vol. 50 > No. 2 > 220148

Next Article Previous Article

Xia J Z, Sun H M, Hu S H, et al. 3D laser point cloud clustering method based on image information constraints[J]. Opto-Electron Eng, 2023, 50(2): 220148. doi: 10.12086/oee.2023.220148

Citation:

Xia J Z, Sun H M, Hu S H, et al. 3D laser point cloud clustering method based on image information constraints[J]. Opto-Electron Eng, 2023, 50(2): 220148. doi: 10.12086/oee.2023.220148

3D laser point cloud clustering method based on image information constraints

School of Mechanical Engineering and Mechanics, Ningbo University, Ningbo, Zhejiang 315000, China

Fund Project: Public Welfare Project of Zhejiang Natural Science Foundation (LGG21E050008), the Ningbo 2025 Science and Technology Innovation Major Project (2019B10100), and Public Welfare Project of Ningbo Science and Technology Foundation (2022S004)

More Information

^*Corresponding author: liangdongtai@nbu.edu.cn

Received Date 30 June 2022

Revised Date 15 October 2022

Accepted Date 28 November 2022

Available Online 16 February 2023

Published Date 16 February 2023

Abstract

Abstract

Aiming at the requirement of fast clustering and segmentation of 3D point clouds for mobile robots in the process of perception of unknown environments, a 3D laser point cloud clustering method based on image information constraints is proposed. Firstly, the effective 3D environment information is obtained through point cloud preprocessing, and the RANSAC method is used to segment and eliminate the ground point cloud. Secondly, the sensor data is introduced into the YOLOv5 target detection algorithm after completing the spatiotemporal registration, and the K-means clustering algorithm of the 3D point cloud is improved. The detection frame range of the 2D image target is used to constrain the 3D point cloud and reduce the interference of non-target objects. The parameter initialization of the point cloud clustering algorithm is realized based on the image detection information. The clustering results are optimized by the intra-class outlier elimination method. Finally, the mobile robot hardware platform is built, and the box is tested. The experimental results show that the clustering accuracy and clustering time of the method in this paper are 86.96% and 23 ms, respectively, which can be used in mobile robot navigation and obstacle avoidance, autonomous handling, and other fields.
- moving robot /
- LiDAR /
- target detection /
- point cloud clustering

FullText(HTML)

References

[1]	姬长英, 周俊. 农业机械导航技术发展分析[J]. 农业机械学报, 2014, 45(9): 44−54. doi: 10.6041/j.issn.1000-1298.2014.09.008 CrossRef Google Scholar Ji C Y, Zhou J. Current situation of navigation technologies for agricultural machinery[J]. Trans Chin Soc Agric Mach, 2014, 45(9): 44−54. doi: 10.6041/j.issn.1000-1298.2014.09.008 CrossRef Google Scholar
[2]	赵佳琦, 周勇, 何欣, 等. 基于深度学习的点云分割研究进展分析[J]. 电子与信息学报, 2022, 44(12): 4426−4440. doi: 10.11999/JEIT210972 CrossRef Google Scholar Zhao J Q, Zhou Y, He X, et al. Research progress analysis of point cloud segmentation based on deep learning[J]. J Electron Inf Technol, 2022, 44(12): 4426−4440. doi: 10.11999/JEIT210972 CrossRef Google Scholar
[3]	Su H, Maji S, Kalogerakis E, et al. Multi-view convolutional neural networks for 3D shape recognition[C]//2015 IEEE International Conference on Computer Vision, 2015: 945–953. https://doi.org/10.1109/ICCV.2015.114. Google Scholar
[4]	Maturana D, Scherer S. VoxNet: a 3D convolutional neural network for real-time object recognition[C]//2015 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS), 2015: 922–928. https://doi.org/10.1109/IROS.2015.7353481. Google Scholar
[5]	Qi C R, Su H, Mo K C, et al. PointNet: deep learning on point sets for 3D classification and segmentation[C]//2017 IEEE Conference on Computer Vision and Pattern Recognition, 2017: 77–85. https://doi.org/10.1109/CVPR.2017.16. Google Scholar
[6]	Qi C R, Yi L, Su H, et al. PointNet++: deep hierarchical feature learning on point sets in a metric space[C]//Proceedings of the 31st International Conference on Neural Information Processing Systems, 2017: 5105–5114. Google Scholar
[7]	金立生, 贺阳, 王欢欢, 等. 基于自适应阈值DBSCAN的路侧点云分割算法[J]. 汽车工程, 2022, 44(7): 987−996. doi: 10.19562/j.chinasae.qcgc.2022.07.005 CrossRef Google Scholar Jin L S, He Y, Wang H H, et al. Point cloud segmentation algorithm based on adaptive threshold DBSCAN for roadside LiDAR[J]. Automot Eng, 2022, 44(7): 987−996. doi: 10.19562/j.chinasae.qcgc.2022.07.005 CrossRef Google Scholar
[8]	王子洋, 李琼琼, 张子蕴, 等. 应用于无人驾驶车辆的点云聚类算法研究进展[J]. 世界科技研究与发展, 2021, 43(3): 274−285. doi: 10.16507/j.issn.1006-6055.2020.12.025. CrossRef Google Scholar Wang Z Y, Li Q Q, Zhang Z Y, et al. Research progress of unmanned vehicle point cloud clustering algorithm[J]. World Sci-Tech R& D, 2021, 43(3): 274−285. doi: 10.16507/j.issn.1006-6055.2020.12.025. CrossRef Google Scholar
[9]	魏玉锋, 梁冬泰, 梁丹, 等. 基于多模态信息的机器人视觉识别与定位研究[J]. 光电工程, 2018, 45(2): 170650. doi: 10.12086/oee.2018.170650 CrossRef Google Scholar Wei Y F, Liang D T, Liang D, et al. Visual identification and location algorithm for robot based on the multimodal information[J]. Opto-Electron Eng, 2018, 45(2): 170650. doi: 10.12086/oee.2018.170650 CrossRef Google Scholar
[10]	杨俊闯, 赵超. K-Means聚类算法研究综述[J]. 计算机工程与应用, 2019, 55(23): 7−14,63. doi: 10.3778/j.issn.1002-8331.1908-0347 CrossRef Google Scholar Yang J C, Zhao C. Survey on K-means clustering algorithm[J]. Comput Eng Appl, 2019, 55(23): 7−14,63. doi: 10.3778/j.issn.1002-8331.1908-0347 CrossRef Google Scholar
[11]	李沛婷, 赵庆展, 田文忠, 等. 结合无人机载LiDAR点云法向量的K-means++聚类精简[J]. 国土资源遥感, 2020, 32(2): 103−110. doi: 10.6046/gtzyyg.2020.02.14 CrossRef Google Scholar Li P T, Zhao Q Z, Tian W Z, et al. Point cloud simplification method combining K-means++ clustering with UAV LiDAR point cloud normal vectors[J]. Remote Sens Land Resour, 2020, 32(2): 103−110. doi: 10.6046/gtzyyg.2020.02.14 CrossRef Google Scholar
[12]	刘亚坤, 李永强, 刘会云, 等. 基于改进RANSAC算法的复杂建筑物屋顶点云分割[J]. 地球信息科学学报, 2021, 23(8): 1497−1507. doi: 10.12082/dqxxkx.2021.200742 CrossRef Google Scholar Liu Y K, Li Y Q, Liu H Y, et al. An improved RANSAC algorithm for point cloud segmentation of complex building roofs[J]. J Geo-Inf Sci, 2021, 23(8): 1497−1507. doi: 10.12082/dqxxkx.2021.200742 CrossRef Google Scholar
[13]	潘济宇, 张水强, 苏志龙, 等. 基于数字图像相关的水下螺旋桨三维变形测量[J]. 光学学报, 2021, 41(12): 1212001. doi: 10.3788/AOS202141.1212001 CrossRef Google Scholar Pan J Y, Zhang S Q, Su Z L, et al. Measuring three-dimensional deformation of underwater propellers based on digital image correlation[J]. Acta Opt Sin, 2021, 41(12): 1212001. doi: 10.3788/AOS202141.1212001 CrossRef Google Scholar
[14]	Yuan C J, Liu X Y, Hong X P, et al. Pixel-level extrinsic self calibration of high resolution LiDAR and camera in targetless environments[J]. IEEE Robot Autom Lett, 2021, 6(4): 7517−7524. doi: 10.1109/LRA.2021.3098923 CrossRef Google Scholar
[15]	许德刚, 王露, 李凡. 深度学习的典型目标检测算法研究综述[J]. 计算机工程与应用, 2021, 57(8): 10−25. doi: 10.3778/j.issn.1002-8331.2012-0449 CrossRef Google Scholar Li D G, Wang L, Li F. Review of typical object detection algorithms for deep learning[J]. Comput Eng Appl, 2021, 57(8): 10−25. doi: 10.3778/j.issn.1002-8331.2012-0449 CrossRef Google Scholar

Overview

Overview

3D laser point cloud clustering recognition is one of the important ways for mobile robots to perceive the environment. The main purpose is to obtain the semantics, position, size and attitude of the target in three-dimensional space. How to use sensor data to quickly and effectively extract target object information from complex environments containing ground point clouds is of great research significance.

This paper proposes a 3D laser point cloud clustering method based on image information constraints to meet the needs of fast clustering and segmentation of 3D point clouds for mobile robots in the process of perception of unknown environments. First of all, considering the huge amount of laser point cloud data, point cloud preprocessing operations of the region of interest selection and voxel grid down sampling filtering are adopted. To prevent the ground point cloud from being falsely detected as valid data, the ground point cloud is segmented and culled by the RANSAC method. In order to construct the spatial mapping relationship of the lidar and camera, the internal and external parameters are obtained by Zhang’s calibration method and the pixel-level external parameter self-calibration method without a calibration board, and the calculated parameters enable spatial synchronization of point clouds and images. The time nearest neighbor matching method is adopted to complete the multi-sensor time registration based on the lidar timestamp. Secondly, the YOLOv5 target detection algorithm is introduced to improve the K-means clustering algorithm of the 3D point cloud. The detection frame range of the 2D image target is used to constrain the 3D point cloud to reduce the interference of non-target objects. The parameter initialization of the point cloud clustering algorithm is realized based on the image detection information, which effectively solves the problem of poor clustering effect caused by the difficulty in determining the initial parameter setting of the traditional 3D point cloud K-means clustering, and then uses the intra-class outlier elimination method to optimize the clustering results. Finally, we build a mobile robot hardware platform and test the box that are compared with DBSCAN, Euclidean Clustering, K-means, and K-means++ algorithms. In the case of densely arranged boxes, it has better detection robustness.

After testing with 50 frames of random data, the experimental results show that the clustering accuracy and clustering time of this method are 86.96% and 23 ms, respectively, which are better than other algorithms, and can be used in mobile robot navigation and obstacle avoidance, autonomous handling, and other fields.
