STransMNet: a stereo matching method with swin transformer fusion

Wang Gaoping; Li Xun; Jia Xuefang; Li Zhewen; Wang Wenjie

doi:10.12086/oee.2023.220246

Article navigation > Opto-Electronic Engineering > 2023 Vol. 50 > No. 4 > 220246

Next Article Previous Article

Wang G P, Li X, Jia X F, et al. STransMNet: a stereo matching method with swin transformer fusion[J]. Opto-Electron Eng, 2023, 50(4): 220246. doi: 10.12086/oee.2023.220246

Citation:

Wang G P, Li X, Jia X F, et al. STransMNet: a stereo matching method with swin transformer fusion[J]. Opto-Electron Eng, 2023, 50(4): 220246. doi: 10.12086/oee.2023.220246

STransMNet: a stereo matching method with swin transformer fusion

1.
School of Electronics and Information, Xi'an Polytechnic University, Xi'an, Shaanxi 710600, China
2.
Xi'an Polytechnic University Branch of Shaanxi Artificial Intelligence Joint Laboratory, Xi'an, Shaanxi 710600, China

Fund Project: National Natural Science Foundation of China (61971339) and Shaanxi Natural Science Basic Research Project (2022JM407).

More Information

^*Corresponding author: lixun@xpu.edu.cn

Received Date 08 October 2022

Revised Date 11 January 2023

Accepted Date 19 January 2023

Published Date 25 April 2023

Abstract

Abstract

Feature extraction in the CNN-based stereo matching models has the problem that it is difficult to learn global and long-range context information. To solve this problem, an improved model STransMNet stereo matching network based on the Swin Transformer is proposed in this paper. We analyze the necessity of the aggregated local and global context information. Then the difference in matching features during the stereo matching process is discussed. The feature extraction module is improved by replacing the CNN-based algorithm with the Transformer-based Swin Transformer algorithm to enhance the model's ability to capture remote context information. The multi-scale fusion module is added in Swin Transformer to make the output features contain shallow and deep semantic information. The loss function is improved by introducing the feature differentiation loss to enhance the model's attention to details. Finally, the comparative experiments with the STTR-light model are conducted on multiple public datasets, showing that the End-Point-Error (EPE) and the matching error rate of 3 px error are significantly reduced.
- stereo matching /
- Swin Transformer /
- deep learning /
- STransMNet

FullText(HTML)

References

[1]	李珣, 李林鹏, Lazovik A, 等. 基于改进双流卷积递归神经网络的RGB-D物体识别方法[J]. 光电工程, 2021, 48(2): 200069. doi: 10.12086/oee.2021.200069 CrossRef Google Scholar Li X, Li L P, Lazovik A, et al. RGB-D object recognition algorithm based on improved double stream convolution recursive neural network[J]. Opto-Electron Eng, 2021, 48(2): 200069. doi: 10.12086/oee.2021.200069 CrossRef Google Scholar
[2]	Hoffman J, Gupta S, Leong J, et al. Cross-modal adaptation for RGB-D detection[C]//2016 IEEE International Conference on Robotics and Automation (ICRA), 2016: 5032–5039. https://doi.org/10.1109/ICRA.2016.7487708. Google Scholar
[3]	Schwarz M, Milan A, Periyasamy A S, et al. RGB-D object detection and semantic segmentation for autonomous manipulation in clutter[J]. Int J Robot Res, 2018, 37(4–5): 437–451. https://doi.org/10.1177/0278364917713117. Google Scholar
[4]	曹春林, 陶重犇, 李华一, 等. 实时实例分割的深度轮廓段落匹配算法[J]. 光电工程, 2021, 48(11): 210245. doi: 10.12086/oee.2021.210245 CrossRef Google Scholar Cao C L, Tao C B, Li H Y, et al. Deep contour fragment matching algorithm for real-time instance segmentation[J]. Opto-Electron Eng, 2021, 48(11): 210245. doi: 10.12086/oee.2021.210245 CrossRef Google Scholar
[5]	Scharstein D, Szeliski R. A taxonomy and evaluation of dense two-frame stereo correspondence algorithms[J]. Int J Comput Vision, 2002, 47(1–3): 7–42. https://doi.org/10.1023/A:1014573219977. Google Scholar
[6]	Tippetts B, Lee D J, Lillywhite K, et al. Review of stereo vision algorithms and their suitability for resource-limited systems[J]. J Real-Time Image Proc, 2016, 11(1): 5−25. doi: 10.1007/s11554-012-0313-2 CrossRef Google Scholar
[7]	Hirschmuller H. Stereo processing by semiglobal matching and mutual information[J]. IEEE Trans Pattern Anal Mach Intell, 2008, 30(2): 328−341. doi: 10.1109/TPAMI.2007.1166 CrossRef Google Scholar
[8]	Mayer N, Ilg E, Häusser P, et al. A large dataset to train convolutional networks for disparity, optical flow, and scene flow estimation[C]//Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition, 2016: 4040–4048. https://doi.org/10.1109/CVPR.2016.438. Google Scholar
[9]	Kendall A, Martirosyan H, Dasgupta S, et al. End-to-end learning of geometry and context for deep stereo regression[C]//Proceedings of the IEEE International Conference on Computer Vision, 2017: 66–75. https://doi.org/10.1109/ICCV.2017.17. Google Scholar
[10]	Chang J R, Chen Y S. Pyramid stereo matching network[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2018: 5410–5418. https://doi.org/10.1109/CVPR.2018.00567. Google Scholar
[11]	Xu H F, Zhang J Y. AANet: Adaptive aggregation network for efficient stereo matching[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2020: 1956–1965. https://doi.org/10.1109/CVPR42600.2020.00203. Google Scholar
[12]	Khamis S, Fanello S, Rhemann C, et al. StereoNet: Guided hierarchical refinement for real-time edge-aware depth prediction[C]//Proceedings of the 15th European Conference on Computer Vision, 2018: 596–613. https://doi.org/10.1007/978-3-030-01267-0_35. Google Scholar
[13]	Chopra S, Hadsell R, LeCun Y. Learning a similarity metric discriminatively, with application to face verification[C]//2005 IEEE Computer Society Conference on Computer Vision and Pattern Recognition (CVPR'05), 2005, 1: 539–546. https://doi.org/10.1109/CVPR.2005.202. Google Scholar
[14]	He K M, Zhang X Y, Ren S Q, et al. Spatial pyramid pooling in deep convolutional networks for visual recognition[J]. IEEE Trans Pattern Anal Mach Intell, 2015, 37(9): 1904−1916. doi: 10.1109/TPAMI.2015.2389824 CrossRef Google Scholar
[15]	Zhao H S, Shi J P, Qi X J, et al. Pyramid scene parsing network[C]//Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition, 2017: 6230–6239. https://doi.org/10.1109/CVPR.2017.660. Google Scholar
[16]	Nie G Y, Cheng M M, Liu Y, et al. Multi-level context ultra-aggregation for stereo matching[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2019: 3278–3286. https://doi.org/10.1109/CVPR.2019.00340. Google Scholar
[17]	Zhang F H, Prisacariu V, Yang R G, et al. Ga-Net: guided aggregation net for end-to-end stereo matching[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2019: 185–194. https://doi.org/10.1109/CVPR.2019.00027. Google Scholar
[18]	Chabra R, Straub J, Sweeney C, et al. StereoDRNet: dilated residual StereoNet[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2019: 11778–11787. https://doi.org/10.1109/CVPR.2019.01206. Google Scholar
[19]	Li Z S, Liu X T, Drenkow N, et al. Revisiting stereo depth estimation from a sequence-to-sequence perspective with Transformers[C]//Proceedings of the IEEE/CVF International Conference on Computer Vision, 2021: 6177–6186. https://doi.org/10.1109/ICCV48922.2021.00614. Google Scholar
[20]	Tulyakov S, Ivanov A, Fleuret F. Practical deep stereo (PDS): toward applications-friendly deep stereo matching[C]//Proceedings of the 32nd International Conference on Neural Information Processing Systems, 2018: 5875–5885. https://doi.org/10.5555/3327345.3327488. Google Scholar
[21]	Hu J, Shen L, Sun G. Squeeze-and-excitation networks[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2018: 7132–7141. https://doi.org/10.1109/CVPR.2018.00745. Google Scholar
[22]	Woo S, Park J, Lee J Y, et al. CBAM: convolutional block attention module[C]//Proceedings of the 15th European Conference on Computer Vision, 2018: 3–19. https://doi.org/10.1007/978-3-030-01234-2_1. Google Scholar
[23]	Dosovitskiy A, Beyer L, Kolesnikov A, et al. An image is worth 16x16 words: transformers for image recognition at scale[C]//9th International Conference on Learning Representations, 2021. Google Scholar
[24]	Han K, Xiao A, Wu E H, et al. Transformer in transformer[C]//Proceedings of the 35th Conference on Neural Information Processing Systems, 2021: 15908–15919. Google Scholar
[25]	Fang Y X, Liao B C, Wang X G, et al. You only look at one sequence: rethinking transformer in vision through object detection[C]//Proceedings of the 35th Conference on Neural Information Processing Systems, 2021: 26183–26197. Google Scholar
[26]	Liu Z, Lin Y T, Cao Y, et al. Swin transformer: hierarchical vision transformer using shifted windows[C]//Proceedings of the IEEE/CVF International Conference on Computer Vision, 2021: 9992–10002. https://doi.org/10.1109/ICCV48922.2021.00986. Google Scholar
[27]	Courty N, Flamary R, Tuia D, et al. Optimal transport for domain adaptation[J]. IEEE Trans Pattern Anal Mach Intell, 2017, 39(9): 1853−1865. doi: 10.1109/TPAMI.2016.2615921 CrossRef Google Scholar
[28]	Liu Y B, Zhu L C, Yamada M, et al. Semantic correspondence as an optimal transport problem[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2020: 4463–4472. https://doi.org/10.1109/CVPR42600.2020.00452. Google Scholar
[29]	Sarlin P E, DeTone D, Malisiewicz T, et al. Superglue: learning feature matching with graph neural networks[C]//Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition, 2020: 4937–4946. https://doi.org/10.1109/CVPR42600.2020.00499. Google Scholar
[30]	Cao H, Wang Y Y, Chen J, et al. Swin-Unet: Unet-like pure Transformer for medical image segmentation[C]//Proceedings of the International Conference on Computer Vision, 2022: 205–218. https://doi.org/10.1007/978-3-031-25066-8_9. Google Scholar
[31]	Menze M, Geiger A. Object scene flow for autonomous vehicles[C]//Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition, 2015: 3061–3070. https://doi.org/10.1109/CVPR.2015.7298925. Google Scholar
[32]	He K M, Girshick R, Dollár P. Rethinking ImageNet pre-training[C]//Proceedings of the IEEE/CVF International Conference on Computer Vision, 2019: 4917–4926. https://doi.org/10.1109/ICCV.2019.00502. Google Scholar

Overview

Overview

In the stereo matching process, unique pixel features are extracted by aggregating local and global context information. The pixel features on the pole lines of the left and right images are then matched. With the rapid application of deep learning (DL) methods in the field of image processing, end-to-end neural networks of DL are used to estimate the disparity maps. Although CNN-based algorithms have excellent feature representation capabilities, they often exhibit limitations in modeling explicit long-range relationships due to the inherent locality of the convolution operations. For objects with weak textures and large differences in shape and size, the results of using CNN alone are often unsatisfactory. To solve this problem, an improved model STransMNet stereo matching network based on the Swin Transformer is proposed in this paper. We analyze the necessity of the aggregated local and global context information. Then the difference in matching features during the stereo matching process is discussed. The feature extraction module is improved by replacing the CNN-based algorithm with the Transformer-based Swin Transformer algorithm. The rectified left and right images are fed into Swin Transformer module to generate multi-scale features. Then the multi-scale features are fed into the patch expanding module, the transformation of the linear layer, to make them the same size. Finally, the multi-scale features are fused in the channel dimension. The additional multi-scale fusion module makes the features output by the improved Swin Transformer fuse shallow and deep semantic information. The Swin Transformer used to extract the left and right image features is partially shared by the weights. Although weight sharing makes the model converge faster, our proposed feature differentiation loss can only supervise left or right images. If the full weights are shared, it is equivalent to supervising the left and right images at the same time. Partial weight sharing speeds up the convergence of the model to a certain extent. In addition, partial weight sharing enables the model to extract not only the commonalities of left and right image but also the differences. Furthermore, a feature differentiation loss is proposed in this work to improve the model's ability to pay attention to details. The loss is trained by forcing the classification of pixel features on the epipolar line of the left image, which makes each pixel feature unique. The experimental results on the Sceneflow and KITTI datasets show that our algorithm reduces the 3 px error and EPE compared to the previous algorithms. Experiments show that the proposed STransMNet model reduces the matching error and improves the quality of the disparity maps. It shows that the excellent performance of the improved Swin Transformer in capturing long-distance context information is beneficial to improving the accuracy of stereo matching; feature differentiation loss helps to enhance the detailed information of the disparity maps.
